HARDWARE FEATURES: | |
---|---|
Standards and Protocols |
IEEE 802.11ax/ac/n/a 5GHz, IEEE 802.11ax/b/g/n 2.4GHz, Wi-Fi 6 |
Interface |
3 10/100/1000Mbps LAN Ports, 1 1G/100Mbps WAN Port |
Button | WPS/Reset Button |
Dimensions (W X D X H) | 8.2 × 6.8 × 1.6 in (208.8 × 171.6 × 41.7 mm) |
Antenna | 4× 5 dBi Fixed Omni-Directional Antennas |
WIRELESS FEATURES: | |
Frequency | 2.4GHz & 5GHz |
Signal Rate |
5 GHz@ 1201 Mbps (802.11ax), 2.4 GHz@ 574 Mbps (802.11ax) |
Wireless Functions |
Enable/Disable Wireless Radio, WMM |
Wireless Security | WPA-PSK / WPA2-PSK/ WPA3 |
SOFTWARE FEATURES: | |
WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
Management |
Access Control, Local Management, Remote Management |
DHCP |
Server, DHCP Client List |
NAT Forwarding |
Port Forwarding, Port Triggering, UPnP, DMZ |
Firewall Security |
SPI Firewall, IP and MAC Address Binding |
Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
VPN Passthrough |
OpenVPN, PPTP supported |
OTHERS: | |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
HARDWARE FEATURES: | |
---|---|
Interface | PCI Express x1 |
Antenna Type |
Two High-Gain Dual Band Antennas, Magnetized Antenna Base |
Chipset | Intel Wi-Fi 6 Chipset |
WIRELESS FEATURES: | |
Wireless Standards |
5 GHz@ IEEE 802.11ax/ac/n/a, 2,4 GHz@ IEEE 802.11ax/n/g/b, Bluetooth 5.0/4.2/4.0 |
Frequency |
2.4-2.4835GHz, 5.180-5.240GHz, 5.745-5.825GHz |
Signal Rate |
2402Mbps at 5GHz, 574Mbps at 2.4GHz |
EIRP |
5 GHz @ 27 dBm (FCC) / 23 dBm (CE) (EIRP), 2,4 GHz @ 26 dBm (FCC) / 20 dBm (CE) (EIRP) |
Wireless Modes | Infrastructure mode |
Wireless Security |
Support 64/128 bit WEP, WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x |
Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
OTHERS: | |
Dimensions | 3.7 x 4.8 x 0.8 in (95.2 x 120.8 x 21.5 mm) |
Certification |
CE, FCC, RoHS, Wi-Fi |
Package Contents |
Archer TX3000E, Magnetized Antenna Base with 1m RF Cable, Two 5 dBi High Gain Antennas, Low-Profile Bracket, Bluetooth Header Cable, Quick Installation Guide, Resource CD |
System Requirements |
Windows 7/8/8.1/10(32/64bits), Windows XP(32/64bits) |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Warranty | 2 years limited warranty. Advanced replacement service is available. |
HARDWARE FEATURES: | |
---|---|
Interface | PCI Express x1 |
Antenna Type | Two High-Gain Dual Band Antennas |
Chipset | Intel Wi-Fi 6 Chipset |
WIRELESS FEATURES: | |
Wireless Standards |
5 GHz@ IEEE 802.11ax/ac/n/a, 2,4 GHz@ IEEE 802.11ax/n/g/b, Bluetooth 5.0/4.2/4.0 |
Frequency |
2.4-2.4835GHz, 5.180-5.240GHz, 5.745-5.825GHz |
Signal Rate |
2402Mbps at 5GHz, 574Mbps at 2.4GHz |
EIRP |
5 GHz @ 27 dBm (FCC) / 23 dBm (CE) (EIRP), 2,4 GHz @ 26 dBm (FCC) / 20 dBm (CE) (EIRP) |
Wireless Modes | Infrastructure mode |
Wireless Security |
Support 64/128 bit WEP, WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x |
Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM |
OTHERS: | |
Dimensions | 3.7 x 4.8 x 0.8 in (95.2 x 120.8 x 21.5 mm) |
Certification |
CE, FCC, RoHS, Wi-Fi |
Package Contents |
Archer TX50E, Two 5 dBi High Gain Antennas, Low-Profile Bracket, Bluetooth Header Cable, Quick Installation Guide, Resource CD |
System Requirements | Windows 10(64-bit) only |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Warranty | 2 years limited warranty. Advanced replacement service is available. |
HARDWARE FEATURES: | |
---|---|
Standards and Protocols |
IEEE 802.11ax/ac/n/a 5GHz, IEEE 802.11ax/b/g/n 2.4GHz, Wi-Fi 6 |
Interface |
4 10/100/1000Mbps LAN Ports, 1 1G/100Mbps WAN Port, 1 USB-A 3.0 Port |
Button |
WPS/Reset Button, Wireless On/Off Button, Power On/off Button |
Power Supply | 12V/2A |
Dimensions (W X D X H) | 261.1 × 134.5 × 41.0 mm |
Antenna | 4 × External Antennas |
WIRELESS FEATURES: | |
Frequency | 2.4GHz & 5GHz |
Signal Rate |
5 GHz@ 2402 Mbps (802.11ax), 2.4 GHz@ 574 Mbps (802.11ax) |
Wireless Functions |
Enable/Disable Wireless Radio, Guest Network, DFS, MU-MIMO, OFDMA |
Wireless Security |
WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x) encryption |
SOFTWARE FEATURES: | |
WAN Type |
Dynamic IP/Static IP/PPPoE/, PPTP (Dual Access)/L2TP (Dual Access)/BigPond |
DHCP |
Server, Client, DHCP Client List, Address Reservation, DHCP relay |
Quality of Service | Advanced Gaming Qos powered by TrendMicro |
Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
Dynamic DNS |
DynDns, Comexe, NO-IP |
VPN Pass-Through |
PPTP, L2TP, IPSec Passthrough |
Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
Management |
Access Control, Local Management, Remote Management |
Guest Network | 2.4GHz guest network × 1, 5GHz guest network × 1 |
OTHERS: | |
Certification |
CE, FCC, IC, RoHS |
System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Manufacturer | TP-Link |
HARDWARE FEATURES: | |
---|---|
Standards and Protocols |
IEEE 802.11ax/ac/n/a 5GHz, IEEE 802.11ax/b/g/n 2.4GHz, Wi-Fi 6 |
Interface |
3 10/100/1000Mbps LAN Ports, 1 1G/100Mbps WAN Port |
Button | WPS/Reset Button |
Dimensions (W X D X H) | 8.2 × 6.8 × 1.6 in (208.8 × 171.6 × 41.7 mm) |
Antenna | 4× 5 dBi Fixed Omni-Directional Antennas |
WIRELESS FEATURES: | |
Frequency | 2.4GHz & 5GHz |
Signal Rate |
5 GHz@ 2402 Mbps (802.11ax), 2.4 GHz@ 574 Mbps (802.11ax) |
Wireless Functions |
Enable/Disable Wireless Radio, WMM |
Wireless Security | WPA-PSK / WPA2-PSK/ WPA3 |
SOFTWARE FEATURES: | |
WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
Management |
Access Control, Local Management, Remote Management |
DHCP |
Server, DHCP Client List |
NAT Forwarding |
Port Forwarding, Port Triggering, UPnP, DMZ |
Firewall Security |
SPI Firewall, IP and MAC Address Binding |
Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
VPN Passthrough |
OpenVPN, PPTP supported |
OTHERS: | |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Standards | IEEE 802.11ax/ac/n/g/b/a |
---|---|
Ports | 1× 2.5 Gbps Ethernet Port (supports IEEE802.3at PoE) |
Button | Reset |
Frequency range | 2.4GHz and 5GHz |
Signal Rate |
5GHz Up to 4804Mbps, 2.4GHz Up to 574Mbps |
EIRP |
CE <20 dBm(2,4 GHz, EIRP), <23 dBm(5 GHz, band1 & band2, EIRP), <30 dBm(5 GHz, , band3, EIRP), FCC <25 dBm (2,4 GHz), <28 dBm (5 GHz) |
Wireless Functions |
Multiple SSIDs (Up to 16 SSIDs, 8 for each band), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm), QoS(WMM), Airtime Fairness, Beamforming, Band Steering, Load Balance, Rate Limit, Link Aggregation, Reboot Schedule, Wireless Schedule, Wireless Statistics based on SSID/AP/Client |
Wireless Security |
Captive Portal Authentication, Access Control, Wireless Mac Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
MANAGEMENT | |
Omada App | Yes |
Centralized Management |
Omada Cloud-Based Controller, Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller |
Cloud Access |
Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) |
Email Alerts | Yes |
LED ON/OFF Control | Yes |
Management MAC Access Control | Yes |
SNMP | v1, v2c |
System Logging Local/Remote Syslog | Local/Remote Syslog |
SSH | Yes |
Web-based Management | HTTP/HTTPS |
L3 Management | Yes |
Multi-site Management | Yes |
Management VLAN | Yes |
Antenna |
2 Dual-Band Antennas, 2.4GHz- 2*3.5dBi, 5GHz- 2*5dBi |
Dimensions | 9.6 × 9.6 × 2.5 in (243 × 243 × 64 mm) |
Power |
802.3at PoE, 12 V DC |
Power Consumption | 18,1 W |
Mounting |
Ceiling /Wall Mounting (Kits included), Junction Box Mounting |
Physical Security Lock | Yes |
Operating Temperature | 0°C~40°C (-32℉~104℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
EAP670, Power Adapter, Ceiling/Wall Mounting Kits, Installation Guide |
System Requirements |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 11, Linux |
Certificates |
CE, FCC, RoHS |
HARDWARE FEATURES: | |
---|---|
Standards and Protocols |
IEEE 802.11ax/ac/n/a 5GHz, IEEE 802.11ax/b/g/n 2.4GHz, Wi-Fi 6 |
Interface |
4 10/100/1000Mbps LAN Ports, 1 1G/100Mbps WAN Port, 1 USB 3.0 Port |
Button |
WPS/Reset Button, Wireless On/Off Button, Power On/off Button, LED On/Off |
Power Supply | 12V/2.5A |
Dimensions (W X D X H) | 10.7 × 5.8 × 1.9 in (272.5 × 147.2 × 49.2 mm) |
Antenna | 6 × External Antennas |
WIRELESS FEATURES: | |
Frequency | 2.4GHz & 5GHz |
Signal Rate |
5 GHz@ 4804 Mbps (802.11ax), 2.4 GHz@ 574 Mbps (802.11ax) |
Wireless Functions |
Enable/Disable Wireless Radio, Guest Network, DFS, MU-MIMO, OFDMA |
Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption |
SOFTWARE FEATURES: | |
WAN Type |
Dynamic IP/Static IP/PPPoE/, PPTP (Dual Access)/L2TP (Dual Access)/BigPond |
DHCP |
Server, Client, DHCP Client List, Address Reservation, DHCP relay |
Quality of Service | Advanced Gaming Qos powered by TrendMicro |
Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
Dynamic DNS |
DynDns, Comexe, NO-IP |
VPN Pass-Through |
PPTP, L2TP, IPSec Passthrough |
Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
Management |
Access Control, Local Management, Remote Management |
Guest Network | 2.4GHz guest network × 1, 5GHz guest network × 1 |
USB Support | |
Supported Partition Formats |
NTFS, exFAT, HFS+, FAT32 |
Supported Functions |
Apple Time Machine, FTP Server, Media Server, Samba Server |
OTHERS: | |
Certification |
CE, FCC, IC, RoHS |
System Requirements |
Microsoft® Windows® XP, Vista™, Windows 7 or Windows 8/8.1/10, MAC® OS, NetWare®, UNIX® or Linux. |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Manufacturer | TP-Link |
HARDWARE FEATURES: | |
---|---|
Processor | 1.5 GHz 64 bit Quad-Core CPU |
Standards and Protocols |
IEEE 802.11ax/ac/n/a 5GHz, IEEE 802.11ax/b/g/n 2.4GHz, Wi-Fi 6 |
Interface |
3 10/100/1000Mbps LAN Ports, 1 2.5G/1G/100Mbps WAN Port, 1 USB 3.0 Port, 1 USB 2.0 Port |
Button |
WPS/Reset Button, Wireless On/Off Button, Power On/off Button, LED On/Off |
Power Supply | 12V/5A |
Dimensions (W X D X H) | 8.3 × 8.3 × 2.0 in (212 × 212 × 51.8 mm) |
Antenna | 8× High-Performance External Antennas |
WIRELESS FEATURES: | |
Frequency | 2.4GHz & 5GHz |
Signal Rate |
5 GHz@ 4804 Mbps (802.11ax), 5 GHz@ 1201 Mbps (802.11ax), 2.4 GHz@ 574 Mbps (802.11ax) |
Wireless Functions |
Enable/Disable Wireless Radio, Guest Network, DFS, MU-MIMO, OFDMA |
Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption |
SOFTWARE FEATURES: | |
WAN Type |
Dynamic IP/Static IP/PPPoE/, PPTP (Dual Access)/L2TP (Dual Access)/BigPond |
DHCP |
Server, Client, DHCP Client List, Address Reservation, DHCP relay |
Quality of Service | Advanced Gaming Qos powered by TrendMicro |
Port Forwarding |
Virtual Server, Port Triggering, UPnP, DMZ |
Dynamic DNS |
DynDns, Comexe, NO-IP |
VPN Pass-Through |
PPTP, L2TP, IPSec Passthrough |
Access Control |
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
Management |
Access Control, Local Management, Remote Management |
Guest Network | 2.4GHz guest network × 1, 5GHz guest network × 1 |
Game Center |
Game Accelerator - Detects and optimizes gaming streams to keep latency as low as possible, Game Statistics - Check real-time latency, system utilization, and game duration on a redesigned dashboard to tweak every detail, Game Protector - Keep your accounts and system safe with HomeCare™ antivirus protection |
OTHERS: | |
Certification |
CE, FCC, IC, RoHS |
System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser |
Environment |
Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Manufacturer | TP-Link |
Standards |
IEEE 802.11 ax/ac/n/a 5 GHz, IEEE 802.11 ax/n/g/b 2,4 GHz |
---|---|
Processor | Qualcomm 1 GHz Quad-core CPU |
Ports | 2 ports 10/100/1000 Mb/s WAN/LAN |
Button | 1 Reset button |
Flash | 16 MB |
SDRAM | 128 MB |
Frequency range | 2.4 GHz and 5 GHz |
Signal Rate |
300 Mbps on 2.4 GHz, 1201 Mbps on 5 GHz |
EIRP |
FCC <30 dBm, CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
Advanced Functions |
Router/ Access Point Mode, Optional Ethernet Backhaul, Guest network, TP-Link Mesh Technology MU-MIMO, Auto Path Selection, Self-Healing, AP Steering, Band Steering, Beamforming |
Wireless Security | WPA-PSK/WPA2-PSK |
Software Features |
Quality of Service - WMM, IPv6 Support, WAN Type - Dynamic IP/Static IP/PPPoE, Local Management, Remote Management, DHCP - Server, Client, Port Forwarding Support, Access Control Blacklist, Firewall Security SPI Firewall, Protocols Supports IPv4 and IPv6, Homecare - Antivirus, Parental Controls, Quality of Service, Speedtest, Monthly Usage Reports, Auto FW Update, Expand for more deco, Guest Network 2.4 GHz guest network * 1 - 5 GHz guest network * 1, Beamformig, Easy setup by Deco App |
Antenna | 4 internal antennas per Deco unit |
Dimensions | Φ4.33 in. × 4.49 in. (Φ110 mm × 114 mm) |
Operating Temperature | 0°C~40°C (-32℉~104℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
1 Deco unit, 1 Power Adapter, 1 RJ45 Ethernet Cable, 1 quick installation guide |
Smartphone/Tablet Requirements |
iOS 9.0 or later, Android 5.0 or later |
Certificates |
CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, VCCI, KC, RoHS |
Standards |
IEEE 802.11 ax/ac/n/a 5 GHz, IEEE 802.11 ax/n/g/b 2,4 GHz |
---|---|
Processor | Qualcomm 1 GHz Quad-core CPU |
Ports | 2 ports 10/100/1000 Mb/s WAN/LAN |
Button | 1 Reset button |
Flash | 16 MB |
SDRAM | 128 MB |
Frequency range | 2.4 GHz and 5 GHz |
Signal Rate |
300 Mbps on 2.4 GHz, 1201 Mbps on 5 GHz |
EIRP |
FCC <30 dBm, CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
Advanced Functions |
Router/ Access Point Mode, Optional Ethernet Backhaul, Guest network, TP-Link Mesh Technology MU-MIMO, Auto Path Selection, Self-Healing, AP Steering, Band Steering, Beamforming |
Wireless Security | WPA-PSK/WPA2-PSK |
Software Features |
Quality of Service - WMM, IPv6 Support, WAN Type - Dynamic IP/Static IP/PPPoE, Local Management, Remote Management, DHCP - Server, Client, Port Forwarding Support, Access Control Blacklist, Firewall Security SPI Firewall, Protocols Supports IPv4 and IPv6, Homecare - Antivirus, Parental Controls, Quality of Service, Speedtest, Monthly Usage Reports, Auto FW Update, Expand for more deco, Guest Network 2.4 GHz guest network * 1 - 5 GHz guest network * 1, Beamformig, Easy setup by Deco App |
Antenna | 4 internal antennas per Deco unit |
Dimensions | Φ4.33 in. × 4.49 in. (Φ110 mm × 114 mm) |
Operating Temperature | 0°C~40°C (-32℉~104℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
2 Deco units, 2 Power Adapters, 1 RJ45 Ethernet Cable, 1 quick installation guide |
Smartphone/Tablet Requirements |
iOS 9.0 or later, Android 5.0 or later |
Certificates |
CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, VCCI, KC, RoHS |
Standards |
IEEE 802.11 ax/ac/n/a 5 GHz, IEEE 802.11 ax/n/g/b 2,4 GHz |
---|---|
Processor | Qualcomm 1 GHz Quad-core CPU |
Ports | 2 ports 10/100/1000 Mb/s WAN/LAN |
Button | 1 Reset button |
Flash | 16 MB |
SDRAM | 128 MB |
Frequency range | 2.4 GHz and 5 GHz |
Signal Rate |
300 Mbps on 2.4 GHz, 1201 Mbps on 5 GHz |
EIRP |
FCC <30 dBm, CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
Advanced Functions |
Router/ Access Point Mode, Optional Ethernet Backhaul, Guest network, TP-Link Mesh Technology MU-MIMO, Auto Path Selection, Self-Healing, AP Steering, Band Steering, Beamforming |
Wireless Security | WPA-PSK/WPA2-PSK |
Software Features |
Quality of Service - WMM, IPv6 Support, WAN Type - Dynamic IP/Static IP/PPPoE, Local Management, Remote Management, DHCP - Server, Client, Port Forwarding Support, Access Control Blacklist, Firewall Security SPI Firewall, Protocols Supports IPv4 and IPv6, Homecare - Antivirus, Parental Controls, Quality of Service, Speedtest, Monthly Usage Reports, Auto FW Update, Expand for more deco, Guest Network 2.4 GHz guest network * 1 - 5 GHz guest network * 1, Beamformig, Easy setup by Deco App |
Antenna | 4 internal antennas per Deco unit |
Dimensions | Φ4.33 in. × 4.49 in. (Φ110 mm × 114 mm) |
Operating Temperature | 0°C~40°C (-32℉~104℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
3 Deco units, 3 Power Adapters, 1 RJ45 Ethernet Cable, 1 quick installation guide |
Smartphone/Tablet Requirements |
iOS 9.0 or later, Android 5.0 or later |
Certificates |
CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, VCCI, KC, RoHS |
Standards |
Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2,4 GHz |
---|---|
Ports | 3 x 10/100/1000 Mb/s ports per Halo unit (WAN/LAN auto-sensing) |
Button | 1 Reset button |
Frequency range | 2.4 GHz and 5 GHz |
Signal Rate |
574 Mbps on 2.4 GHz, 1201 Mbps on 5 GHz |
EIRP | CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
Wireless Security | WPA2-PSK + AES |
Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
Mesh protocol | 802.11k/v |
WAN Type | Dynamic IP/Static IP/PPPoE/PPTP/L2TP |
Management |
Access Control, Local Management, Remote Management |
DHCP |
Server, Address Reservation, DHCP Client List |
Port Forwarding |
Virtual Server, UPnP, DMZ, Port Triggering |
Protocols |
IPv4, IPv6 |
Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
Dimensions | 5 × 3.2 × 3.3 in (128 × 81 × 83,7 mm) |
Operating Temperature | 0°C~40°C (-32℉~104℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
2 Halo H70X units, 2 Power Adapters, 1 RJ45 Ethernet Cable, 1 Quick Installation Guide |
Standards |
Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2,4 GHz |
---|---|
Ports | 3 x 10/100/1000 Mb/s ports per Halo unit (WAN/LAN auto-sensing) |
Button | 1 Reset button |
Frequency range | 2.4 GHz and 5 GHz |
Signal Rate |
574 Mbps on 2.4 GHz, 1201 Mbps on 5 GHz |
EIRP | CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
Wireless Security | WPA2-PSK + AES |
Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
Mesh protocol | 802.11k/v |
WAN Type | Dynamic IP/Static IP/PPPoE/PPTP/L2TP |
Management |
Access Control, Local Management, Remote Management |
DHCP |
Server, Address Reservation, DHCP Client List |
Port Forwarding |
Virtual Server, UPnP, DMZ, Port Triggering |
Protocols |
IPv4, IPv6 |
Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
Dimensions | 5 × 3.2 × 3.3 in (128 × 81 × 83,7 mm) |
Operating Temperature | 0°C~40°C (-32℉~104℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
3 Halo H70X units, 3 Power Adapters, 1 RJ45 Ethernet Cable, 1 Quick Installation Guide |
Standards |
Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2,4 GHz |
---|---|
Ports | 3 x 10/100/1000 Mb/s ports per Halo unit (WAN/LAN auto-sensing) |
Button | 1 Reset button |
Frequency range | 2.4 GHz and 5 GHz |
Signal Rate |
574 Mbps on 2.4 GHz, 2402 Mbps on 5 GHz |
EIRP | CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
Wireless Security | WPA2-PSK + AES |
Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
Mesh protocol | 802.11k/v |
WAN Type | Dynamic IP/Static IP/PPPoE/PPTP/L2TP |
Management |
Access Control, Local Management, Remote Management |
DHCP |
Server, Address Reservation, DHCP Client List |
Port Forwarding |
Virtual Server, UPnP, DMZ, Port Triggering |
Protocols |
IPv4, IPv6 |
Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
Dimensions | 5 × 3.2 × 3.3 in (128 × 81 × 83,7 mm) |
Operating Temperature | 0°C~40°C (-32℉~104℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
2 Halo H80X units, 2 Power Adapters, 1 RJ45 Ethernet Cable, 1 Quick Installation Guide |
Standards |
Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2,4 GHz |
---|---|
Ports | 3 x 10/100/1000 Mb/s ports per Halo unit (WAN/LAN auto-sensing) |
Button | 1 Reset button |
Frequency range | 2.4 GHz and 5 GHz |
Signal Rate |
574 Mbps on 2.4 GHz, 2402 Mbps on 5 GHz |
EIRP | CE <20 dBm (2,4 GHz) <23 dBm (5 GHz) |
Wireless Security | WPA2-PSK + AES |
Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
Mesh protocol | 802.11k/v |
WAN Type | Dynamic IP/Static IP/PPPoE/PPTP/L2TP |
Management |
Access Control, Local Management, Remote Management |
DHCP |
Server, Address Reservation, DHCP Client List |
Port Forwarding |
Virtual Server, UPnP, DMZ, Port Triggering |
Protocols |
IPv4, IPv6 |
Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
Dimensions | 5 × 3.2 × 3.3 in (128 × 81 × 83,7 mm) |
Operating Temperature | 0°C~40°C (-32℉~104℉) |
Storage Temperature | -40℃~70℃ (-40℉~158℉) |
Operating Humidity | 10%~90% non-condensing |
Storage Humidity | 5%~90% non-condensing |
Package Contents |
3 Halo H80X units, 3 Power Adapters, 1 RJ45 Ethernet Cable, 1 Quick Installation Guide |
