Fluke Networks was established in 1992 as FLUKE's branch. In year 2000 company separated from Fluke as independent branch. Since then, company's income has been still growing, securing their leader position in hi-class telecommunication testing devices. Fluke Networks offers specialized instruments for structural cabling testing, wide area networks analysis and networks monitoring. Structural cabling instruments are placed among strict world's leaders. They allows certification measures of telecommunication installations. As one of the very few companies, Fluke Networks has instruments with class IV accuracy to certify cat.7 installations. Among telecommunication solutions company offers wide range of analyzers, allowing detailed network traffic inspection and discovering installed devices. Software and hardware analyzers can verify and rate WANs, working on ATM, Frame Relay, PPP, HDLC, SONET standards. Fluke Networks offer includes:
Atel Electronics is a distributor of Fluke Networks products Manufacturer's website: http://www.flukenetworks.com |
- Computer Network Accessories
-
- » ADVANCED CABLE TESTERS#02903
IntelliTone 200 Pro - signal probe, cable tester (Fluke Networks MT-8200-60-KIT)
Tested cables UTP,
FTP,
STP,
RG59,
RG6,
CCTVSingle pair test yes Wiremap test yes Detected malfunctions break,
short-circuit,
crossed pairs,
reverse pairsDetecting signals Ethernet Detecting connected devices hub,
network cardAdditional features locate cables from large distance (1 meter),
precision locate cable pairs in wispsOperating temperature 0°C ÷ 40°C Operating humidity 5% ÷ 95%,
non-condensingPower 2x 9V 6F22 battery Warranty period 12 months Manufacturer Fluke Networks Toner parameters Dimensions 141x75x32 mm Display LED Control thumbwheel switch Auto power down yes Ouptut power 5V p-p Probe parameters Dimensions 222x48x32 mm Display 8x LED,
1x Sync LEDControl thumbwheel switch,
volume control wheelAuto power down yes
#03091MicroScanner PoE cable tester (Fluke Networks MS-POE)
The new generation of the well-known and valued Microscanner. The new tester does not have a socket for coaxial cables. However, new diagnostic possibilities appeared: PoE voltage measurement, determining whether the port is able to provide sufficient power, identification of the port speed up to 10Gbps.Display LCD,
monochromeTested cables UTP,
FTP,
SSTP,
coaxial 75Ω/50Ω/93ΩConnectors RJ-11,
RJ-45,
FCable length measure 1500ft (460,0 m) Wiremap compliant with TIA-568A/B Remote device detection switch,
POTS,
terminatorTransmission speed indicator 10 Mbps,
100 Mbps,
1000 Mbps,
2.5Gbps,
5Gbps,
10GbpsDetected malfunctions open,
short,
separated pairs,
crossed pairs,
reverse pairsDistance to breakage yes Working in active networks yes Tone generator digital (500 KHz),
analog (400 Hz / 1 KHz)PoE detection yes PoE standards 802.3af,
802.3at,
802.3btDimensions 163x76x36 mm Weight 363 g Warranty 12 months Manufaturer Fluke Networks Compatible with:
#02903 IntelliTone 200
#06106MicroScanner2 cable tester (Fluke Networks MS2-100)
Display LCD,
monochromeTested cables UTP,
FTP,
SSTP,
coaxial 75Ω/50Ω/93ΩConnectors RJ-11,
RJ-45,
FCable length measure 1500ft (460,0 m) with a 0.3m resolution Wiremap compliant with TIA-568A/B Remote device detection switch,
POTS,
terminatorTransmission speed indicator 10 Mbps,
100 Mbps,
1000 MbpsDetected malfunctions open,
short,
separated pairs,
crossed pairs,
reverse pairsDistance to breakage yes Working in active networks yes Tone generator digital (500 KHz),
analog (400 Hz / 1 KHz)PoE detection yes Dimensions 163x76x36 mm Weight 363 g Warranty 12 months Manufaturer Fluke Networks |Compatible with:
#02903 IntelliTone 200
#06249MicroScanner2 Pro Kit (Fluke Networks MS2-KIT)
MicroScanner² Pro Display LCD,
1.75" x 0.85"Tested cables UTP,
STP,
FTP,
RG59,
RG9,
CCTVCable parameters test yes Transmission type detection Half Duplex,
Full DuplexDevice type detection hub,
network cardTransmission speed detection 10 Mbps,
100 Mbps,
1000 MbpsCable length measure 0.5 - 460 m Distance to break/short yes Working in active networks yes Continuous test yes Wiremap test yes Cable faults detection open,
short,
separated pairs,
crossed pairs,
reverse pairsTone generation digital (500 KHz),
analog (400 Hz / 1 KHz)PoE detection yes Dimensions 163x76x36 mm Warranty period 12 months Manufacturer Fluke Networks IntelliTone 200 Probe Single pair test yes Additional features locate cables from large distance,
precision locate cable pairs in wispsOperating temperature 0°C ÷ 40°C Operating humidity 5% ÷ 95%,
non-condensingIncluded accessories:
Line identifiers (1 to 6)
Wiremap adaptor (FL-MT8203-14)
RJ-45/F adaptor(FL-MT8203-15)
RJ-45/aligator adaptor (FL-MT8203-16)
- » VERIFING CABLE TESTERS#05718
LinkIQ cable tester (Fluke Networks LIQ-100)
Tested cables Balanced twisted-pair cabling Unshielded twisted-pair Screened twisted-pair 2-pair and/or 4-pair Qualification autotests 10GBASE-T,
5GBASE-T,
2.5GBASE-T,
1000BASE-T,
100BASE-TX,
10BASE-T,
Wire map Only. Test Speed- 6 seconds for lengths< 70 mWire Map-Only Tests Document wire map,
Length of each pair,
Diagnose split pairs,
User selectable T568A or T568B,
User selectable crossover settings (Straight through,
Half-crossover,
Full-crossover). Test speed- 1 second for lengths < 120 mLength (Maximum) 305 m (1000 ft) Nominal Velocity of Propagation (NVP) User settable Tone Generator Generates digital tones compatible with Fluke Networks IntelliTone probe. Generates analog tones compatible with general analogprobes. Remote ID Locators Use remote ID terminations to identify up to 7 unique ports or office outlets Power Lithium-ion,
3.6 V,
6400 mAh; Life 8 hours typical; Charge time 4.5 hours; Charging temperature range 0 °C to +40 °CWeight 624g Dimensions 8.5 in x 4.5 in Warranty period 12 months Manufacturer Fluke Networks
#05717LinkIQ cable tester (Fluke Networks LIQ-KIT)
Tested cables Balanced twisted-pair cabling Unshielded twisted-pair Screened twisted-pair 2-pair and/or 4-pair Qualification autotests 10GBASE-T,
5GBASE-T,
2.5GBASE-T,
1000BASE-T,
100BASE-TX,
10BASE-T,
Wire map Only. Test Speed- 6 seconds for lengths< 70 mWire Map-Only Tests Document wire map,
Length of each pair,
Diagnose split pairs,
User selectable T568A or T568B,
User selectable crossover settings (Straight through,
Half-crossover,
Full-crossover). Test speed- 1 second for lengths < 120 mLength (Maximum) 305 m (1000 ft) Nominal Velocity of Propagation (NVP) User settable Tone Generator Generates digital tones compatible with Fluke Networks IntelliTone probe. Generates analog tones compatible with general analogprobes. Remote ID Locators Use remote ID terminations to identify up to 7 unique ports or office outlets Power Lithium-ion,
3.6 V,
6400 mAh; Life 8 hours typical; Charge time 4.5 hours; Charging temperature range 0 °C to +40 °CWeight 624g Dimensions 8.5 in x 4.5 in Warranty period 12 months Manufacturer Fluke Networks
-
#08221
FLUKE PRO 3000 - Cable locator
The Pro3000 Analog Tone and Probe is the best choice for toning and tracing wires on non-active networks, specifically for identifying individual pairs with SmartTone™ technology. Angled bed-of-nails clips allow easy access to individual wires, and the RJ11 connector is ideal for use on telephone jacks. The large, loud speaker on the probe allows you to find wires quickly and easily behind drywall, wood, etc. Case attached.Transmitter Solid Frequency 1000 Hz Over Voltage Protection 60VDC Output Power in Tone Mode 8 dBm 600Ohms Output Voltage 8 VDC dla pomiaru ci±g³o¶ci Battery 9V alkaline Case dimensions 69 x 61 x 36 mm Reciever Battery 9V alkaline Temp. operating (-20 +60)C Temperatura storage (-40 +70)C Dimmensions 249 x 41 x 33 mm Warranty 12 months
#08220IntelliTone 200 Probe (Fluke Networks MT-8200-63A)
Interface Main RJ45 port for mapping all 4 UTP / STP cabling pairs. Dimensions 222x48x32 mm Display 8x LED,
1x Sync LEDControl thumbwheel switch,
volume control wheelAuto power down yes
-
