Wireless router 3G, 2x 10/100 RJ-45 (WAN + LAN) + 1x 802.11a/b/g (WLAN) + 1x USB (ORing TAR-3120-M12)
ORing’s Transporter series cellular VPN router is designed for industrial and rolling stock wireless applications, such as vehicle, and railway applications.
TAR-3120-M12 is a reliable Dual-RF IEEE802.11a/b/g and IEEE 802.11b/g cellular VPN router with 2 ports LAN which is fully compliant with EN50155 certification. It supports 802.1X and MAC filter for security control. It can be configured to operate in 3 modes of routing function: Dynamic/Static IP route, PPPoE authentication, and Cellular Modem dial-up. Users can set up WLAN environment to fulfill demands of various applications rapidly by dialing up cellular modem.
TAR-3120-M12 EN50155 cellular VPN router use M-series connectors to ensure tight, robust connections, and guarantee reliable operation against environmental disturbances, such as vibration and shock. TAR-3120-M12 provides dual RF wireless interfaces, which can provide IEEE 802.11 a/b/g and IEEE 802.11 b/g dual band wireless communication and can be applied to fulfill any demands of wireless applications. TAR-3120-M12 provides dual Ethernet ports in switch mode, so that you can use Daisy Chain to reduce the usage of Ethernet switch ports.
TAR-3120-M12 is a reliable Dual-RF IEEE802.11a/b/g and IEEE 802.11b/g cellular VPN router with 2 ports LAN which is fully compliant with EN50155 certification. It supports 802.1X and MAC filter for security control. It can be configured to operate in 3 modes of routing function: Dynamic/Static IP route, PPPoE authentication, and Cellular Modem dial-up. Users can set up WLAN environment to fulfill demands of various applications rapidly by dialing up cellular modem.
TAR-3120-M12 EN50155 cellular VPN router use M-series connectors to ensure tight, robust connections, and guarantee reliable operation against environmental disturbances, such as vibration and shock. TAR-3120-M12 provides dual RF wireless interfaces, which can provide IEEE 802.11 a/b/g and IEEE 802.11 b/g dual band wireless communication and can be applied to fulfill any demands of wireless applications. TAR-3120-M12 provides dual Ethernet ports in switch mode, so that you can use Daisy Chain to reduce the usage of Ethernet switch ports.
| Physical Ports | |
|---|---|
| 10/100Base-T(X) Ports | RJ45 Auto MDI/MDIX 2 (M12 connector – D coding) |
| WLAN Interface | |
| WAN Connection Type | Static/Dynamic IP, PPPoE, 3G Modem dial-up |
| Antenna and Connector | 2 x 2 dBi (b/g mode) / 3dBi (a mode) on Reverse SMA connector, 2 x 2 dBi (Cellular modem) on Reverse SMA connector |
| Radio Frequency Type | DSSS, OFDM |
| Modulation | |
| IEEE 802.11a | OFDM with BPSK, QPSK, 16QAM, 64QAM |
| IEEE 802.11b | CCK, DQPSK, DBPSK |
| IEEE 802.11g | OFDM with BPSK, QPSK, 16QAM, 64QAM |
| Frequency Band | America / FCC 2.412~2.462 GHz (11 channels), 5.15 to 5.825 GHz (13 channels), Europe CE / ETSI 2.412~2.472 Ghz (13 channels), 5.15 to 5.724 GHz (19 channels) |
| Transmission Rate | |
| IEEE 802.11b | 1 / 2 / 5.5 / 11 Mbps |
| IEEE 802.11a/g | 6 / 9 / 12 / 18 / 24 / 36 / 48 / 54 Mbps |
| Transmit Power | IEEE802.11a/b/g 20dBm max |
| Receiver Sensitivity | |
| IEEE 802.11a | -77dBm±2.0dB @ 54Mbps PER< 10% |
| IEEE 802.11b | -86dBm±1.5dB @ 11Mbps PER< 8%; |
| IEEE 802.11g | -78dBm±1.5dB @ 54Mbps PER< 10% |
| Encryption Security | |
| WEP | (64-bit and 128-bit key supported) |
| WPA/WPA2 | 802.11i(WEP and AES encryption) |
| WPA-PSK | (256-bit key pre-shared key supported) |
| 802.1X | Authentication supported |
| TKIP | encryption |
| Wireless Security | SSID broadcast disable |
| LED Indicators | |
| Power Indicator | Green for Power indicator |
| RJ45 Port Indicator | Green for port Link/ Act at 100Mbps. Amber for port Link/ Act at 10Mbps. |
| WLAN LEDs | Green for WLAN Link/ Act |
| Cellular modem LED | Green for Cellular modem Link/ Act |
| Fault Contact | |
| Relay | Relay output to carry capacity of 3A at 24VDC |
| Power | |
| Redundant Input Power | Dual DC inputs. 12~48VDC on M23 connector (24VDC typ) |
| Power Consumption | 9.6 W |
| Overload Current Protection | Present |
| Reverse Polarity Protection | Present |
| Physical Characteristics | |
| Enclosure | IP-40 |
| Dimensions | (W x D x H) 125(W) x 65(D) x 196(H) mm (4.92 x 2.56 x 7.72 inch.) |
| Weight (g) | 1050 g |
| Environmental | |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Operating Temperature | -20 to 70°C (-4 to 158°F) |
| Operating Humidity | 5% to 95% Non-condensing |
| EMI | FCC Part 15, CISPR (EN55022) class A, EN50155 (EN50121-3-2) |
| EMS | EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), |
| EN61000-4-8, EN61000-4-11 | |
| Shock | IEC60068-2-27, EN61373 |
| Free Fall | IEC60068-2-32 |
| Vibration | IEC60068-2-6, EN61373 |
| Cooling | EN60068-2-1 |
| Dry Heat | EN60068-2-2 |
| Safety | EN60950-1 |
| Warranty | 3 years |
Net Price:
 Call |
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
