New Items in Atel Electronics

NEW ITEMS


  • Computer Network Accessories
    • Switches
      • » GIGABIT ETHERNET / INTELLIGENT (SMART SWITCHES)
          #07023

          Smart switch, 8x 10/100/1000 RJ-45, 2 slide-in SFP, 9" (19") (Edge-corE ECS2100-10T)

          Ports
          RJ-45 10/100/1000BASE-T ports 8
          SFP ports 2
          Console Port 1
          Performance
          Forwarding Rate [Mpps] 14.9
          Switching Capability [Gbps] 20
          SDRAM 256MB
          L2 Features
          Flow Control IEEE 802.3x for full duplex mode,
          Back-Pressure for half duplex mode
          Spanning Tree Protocol (STP) IEEE 802.1D Spanning Tree Protocol (STP),
          IEEE 802.1s Multiple Spanning Tree Protocol (MSTP),
          BPDU Guard,
          Root Guard
          VLAN Supports 4K IEEE 802.1Q VLANs,
          Port-based VLANs,
          IP based VLANs,
          Private VLAN s,
          Voice VLAN,
          Q-in-Q,
          Select Q-in-Q
          Link Aggregation Static Trunk,
          IEEE 802.3ad Link Aggregation Control Protoco
          IGMP Support IGMP v1/v2/v3 snooping,
          IGMP v1/v2/v3 proxy,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier
          Others MVR (Multicast VLAN Registration),
          Auto-negotiation for port speed and duplex mode
          Security
          IEEE 802.1x Port-based,
          MAC-based,
          VLAN Assignment,
          Guest VLAN,
          QoS assignment
          Quality of Service (QoS) CoS(IEEE 802.1p,
          IP Precedence,
          DSCP,
          TCP/UDP,
          ACL),
          H/W Queues 8
          Priority Queue Scheduling WRR,
          Strict Priority,
          Hybrid
          Rate Limiting Ingress,
          Egress
          Others ACL L2/L3/L4,
          HTTP and SSL ( Secured Web),
          IP Source Guard,
          MAC Filter,
          Port Security (MAC Based) - Static/Dynamic,
          RADIUS (RFC2138) Authentication/Accounting,
          SSH v1.5/ v2.0 (Secured Telnet Session),
          TACACS+ Accounting,
          Username/Password Authentication (Local/Remote)
          Management
          Switch Management Telnet WEB management
          Firmware and Configuration Upgrade via TFTP/HTTP
          Remote Monitoring (RMON) Support group 1, 2, 3, 9
          SNMP version 1, 2c,
          3
          Others Support - DHCP Client,
          DHCP Server,
          DNS client,
          proxy,
          HTTP Server,
          HTTPs,
          SSHv2,
          System Syslog,
          LLDP,
          sFlow
          IPv6 Features IPv4/IPv6 Dual Protocol stack,
          IPv6 Address Types Stack- Unicast,
          ICMPv6,
          ICMPv6 Redirect (Host),
          Stateless Auto configuration,
          IPv6 Neighbor Discovery,
          SNMP over IPv6,
          HTTP po IPv6,
          DHCPv6 Client,
          Remote IPv6 Ping,
          NTPv6
          General
          Power Supply 100-240 VAC,
          50/60Hz
          Max Power Consumption (Watts) 8W
          Flash Memory 32MB
          MAC Address Table 8K
          LED Indicators Port,
          Uplink,
          System,
          Diagnostic
          Dimensions 196 x 117 x 36 mm
          Weight 816g
          Operating temperature 0 ÷ 50°C
          Operating humidity 10% ÷ 90%,
          niekondensująca
          Certyfication CE Mark,
          FCC Class A,
          Safety Compliance CB,
          Safety Compliance UL
          Manufacturer Edge-corE
          EDGE-CORE
          Smart switch, 8x 10/100/1000 RJ-45, 2 slide-in SFP, 9" (19") (Edge-corE ECS2100-10T)
          for special orders only
          Net Price: 187.00 USD
          product card»
          #07022

          Smart switch, 24x 10/100/1000 RJ-45, 4 slide-in SFP, 19" (Edge-corE ECS2100-28T)

          Ports
          RJ-45 10/100/1000BASE-T ports 24
          SFP ports 4
          Console Port 1
          Performance
          Forwarding Rate [Mpps] 41.7
          Switching Capability [Gbps] 56
          SDRAM 256MB
          L2 Features
          Flow Control IEEE 802.3x for full duplex mode,
          Back-Pressure for half duplex mode
          Spanning Tree Protocol (STP) IEEE 802.1D Spanning Tree Protocol (STP),
          IEEE 802.1s Multiple Spanning Tree Protocol (MSTP),
          BPDU Guard,
          Root Guard
          VLAN Supports 4K IEEE 802.1Q VLANs,
          Port-based VLANs,
          IP based VLANs,
          Private VLAN s,
          Voice VLAN,
          Q-in-Q,
          Select Q-in-Q
          Link Aggregation Static Trunk,
          IEEE 802.3ad Link Aggregation Control Protoco
          IGMP Support IGMP v1/v2/v3 snooping,
          IGMP v1/v2/v3 proxy,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier
          Others MVR (Multicast VLAN Registration),
          Auto-negotiation for port speed and duplex mode
          Security
          IEEE 802.1x Port-based,
          MAC-based,
          VLAN Assignment,
          Guest VLAN,
          QoS assignment
          Quality of Service (QoS) CoS(IEEE 802.1p,
          IP Precedence,
          DSCP,
          TCP/UDP,
          ACL),
          H/W Queues 8
          Priority Queue Scheduling WRR,
          Strict Priority,
          Hybrid
          Rate Limiting Ingress,
          Egress
          Others ACL L2/L3/L4,
          HTTP and SSL ( Secured Web),
          IP Source Guard,
          MAC Filter,
          Port Security (MAC Based) - Static/Dynamic,
          RADIUS (RFC2138) Authentication/Accounting,
          SSH v1.5/ v2.0 (Secured Telnet Session),
          TACACS+ Accounting,
          Username/Password Authentication (Local/Remote)
          Management
          Switch Management Telnet WEB management
          Firmware and Configuration Upgrade via TFTP/HTTP
          Remote Monitoring (RMON) Support group 1, 2, 3, 9
          SNMP version 1, 2c,
          3
          Others Support - DHCP Client,
          DHCP Server,
          DNS client,
          proxy,
          HTTP Server,
          HTTPs,
          SSHv2,
          System Syslog,
          LLDP,
          sFlow
          IPv6 Features IPv4/IPv6 Dual Protocol stack,
          IPv6 Address Types Stack- Unicast,
          ICMPv6,
          ICMPv6 Redirect (Host),
          Stateless Auto configuration,
          IPv6 Neighbor Discovery,
          SNMP over IPv6,
          HTTP po IPv6,
          DHCPv6 Client,
          Remote IPv6 Ping,
          NTPv6
          General
          Power Supply 100-240 VAC,
          50/60Hz
          Max Power Consumption (Watts) 20W
          Flash Memory 32MB
          MAC Address Table 8K
          LED Indicators Port,
          Uplink,
          System,
          Diagnostic
          Dimensions 440 x 220 x 44 mm
          Weight 2.2 kg
          Operating temperature 0 ÷ 50°C
          Operating humidity 10% ÷ 90%,
          niekondensująca
          Certyfication CE Mark,
          FCC Class A,
          Safety Compliance CB,
          Safety Compliance UL
          Manufacturer Edge-corE
          EDGE-CORE
          Smart switch, 24x 10/100/1000 RJ-45, 4 slide-in SFP, 19" (Edge-corE ECS2100-28T)
          for special orders only
          Net Price: 323.00 USD
          product card»
          #07027

          Smart switch, 24x 10/100/1000 RJ-45, 4 slide-in SFP, PoE+, 19" (Edge-corE ECS2100-28P)

          Ports
          RJ-45 10/100/1000BASE-T ports 24
          SFP ports 4
          Console Port 1
          Performance
          Forwarding Rate [Mpps] 41.7
          Switching Capability [Gbps] 56
          SDRAM 256MB
          L2 Features
          Flow Control IEEE 802.3x for full duplex mode,
          Back-Pressure for half duplex mode
          Spanning Tree Protocol (STP) IEEE 802.1D Spanning Tree Protocol (STP),
          IEEE 802.1s Multiple Spanning Tree Protocol (MSTP),
          BPDU Guard,
          Root Guard
          VLAN Supports 4K IEEE 802.1Q VLANs,
          Port-based VLANs,
          IP based VLANs,
          Private VLAN s,
          Voice VLAN,
          Q-in-Q,
          Select Q-in-Q
          Link Aggregation Static Trunk,
          IEEE 802.3ad Link Aggregation Control Protoco
          IGMP Support IGMP v1/v2/v3 snooping,
          IGMP v1/v2/v3 proxy,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier
          Others MVR (Multicast VLAN Registration),
          Auto-negotiation for port speed and duplex mode
          Security
          IEEE 802.1x Port-based,
          MAC-based,
          VLAN Assignment,
          Guest VLAN,
          QoS assignment
          Quality of Service (QoS) CoS(IEEE 802.1p,
          IP Precedence,
          DSCP,
          TCP/UDP,
          ACL),
          H/W Queues 8
          Priority Queue Scheduling WRR,
          Strict Priority,
          Hybrid
          Rate Limiting Ingress,
          Egress
          Others ACL L2/L3/L4,
          HTTP and SSL ( Secured Web),
          IP Source Guard,
          MAC Filter,
          Port Security (MAC Based) - Static/Dynamic,
          RADIUS (RFC2138) Authentication/Accounting,
          SSH v1.5/ v2.0 (Secured Telnet Session),
          TACACS+ Accounting,
          Username/Password Authentication (Local/Remote)
          Management
          Switch Management Telnet WEB management
          Firmware and Configuration Upgrade via TFTP/HTTP
          Remote Monitoring (RMON) Support group 1, 2, 3, 9
          SNMP version 1, 2c,
          3
          Others Support - DHCP Client,
          DHCP Server,
          DNS client,
          proxy,
          HTTP Server,
          HTTPs,
          SSHv2,
          System Syslog,
          LLDP,
          sFlow
          IPv6 Features IPv4/IPv6 Dual Protocol stack,
          IPv6 Address Types Stack- Unicast,
          ICMPv6,
          ICMPv6 Redirect (Host),
          Stateless Auto configuration,
          IPv6 Neighbor Discovery,
          SNMP over IPv6,
          HTTP po IPv6,
          DHCPv6 Client,
          Remote IPv6 Ping,
          NTPv6
          PoE Features
          PoE Budget 200W
          Power Management Present
          802.3af for PoE Present
          Power On/Off per Port Present
          General
          Power Supply 100-240 VAC,
          50/60Hz
          Max Power Consumption (Watts) 260W
          Flash Memory 32MB
          MAC Address Table 8K
          LED Indicators Port,
          Uplink,
          System,
          Diagnostic
          Dimensions 440 x 220 x 44 mm
          Weight 3.1 kg
          Operating temperature 0 ÷ 50°C
          Operating humidity 10% ÷ 90%,
          niekondensująca
          Certyfication CE Mark,
          FCC Class A,
          Safety Compliance CB,
          Safety Compliance UL
          Manufacturer Edge-corE
          EDGE-CORE
          Smart switch, 24x 10/100/1000 RJ-45, 4 slide-in SFP, PoE+, 19" (Edge-corE ECS2100-28P)
          for special orders only
          Net Price: 646.00 USD
          product card»
      • » GIGABIT ETHERNET / L2 MANAGED SWITCHES
          #07126

          Managed switch L2, 24x 10/100/1000 RJ-45, 4x 10G SFP+, 19" (Edge-corE ECS4120-28T)

          Ports
          RJ-45 10/100/1000BASE-T ports 24
          SFP+ 10 Gigabit ports 4
          RJ-45 console port 1
          Performance
          Forwarding Rate [Mpps] 95
          Switching Capability [Gbps] 128
          SDRAM 512MB
          L2 Features
          Flow Control IEEE 802.3x for full duplex mode,
          Back-Pressure for half duplex mode
          Spanning Tree Protocol (STP) IEEE 802.1D (STP). IEEE 802.1w (RSTP),
          IEEE 802.1s (MSTP),
          BPDU Guard,
          BPDU filtering,
          Root Guard,
          Loopback detection
          VLANs support Supports 4K IEEE 802.1Q VLANs,
          Port-based,
          GVRP,
          IEEE 802.1v Protocol-based VLANs,
          Mac-based VLANs,
          IP subnet based VLAN,
          Private VLAN (Traffic Segmentation per port/ VLAN),
          Guest VLAN,
          Voice VLAN,
          VLAN Trunking
          Support IGMP IGMP v1/v2/v3 snooping,
          IGMP Proxy reporting,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier
          Others MVR (Multicast VLAN Registration),
          Supports QinQ,
          Supports select QinQ,
          UDLD,
          G.8032 (ERPS),
          Supports jumbo frames up to 10KB,
          Supports Digital Diagnostic Monitoring (DDM),
          Cable Diagnostic,
          Auto-negotiation for port speed and duplex mode
          Security
          IEEE 802.1x Port-based,
          MAC-based,
          VLAN Assignment,
          Guest VLAN
          Management Access Filtering SNMP,
          WEB,
          Telnet
          TACACS+ Authentication,
          Accounting,
          Authorization
          RADIUS (RFC2138) Authentication,
          Accounting
          Quality of Service (QoS) IEEE 802.1p,
          DSCP,
          8 H/W Queues,
          DiffServ (RFC2474)
          Priority Queue Scheduling WRR,
          Strict Priority,
          Hybrid
          Rate Limiting Ingress,
          Egress
          Others ACL L2/L3/L4,
          HTTP and SSL ( Secured Web),
          Dynamic ARP inspection (DAI),
          Instruction lock (link detection),
          MAC Based Authentication,
          MAC Filter,
          SSH v1.5/ v2.0 (Secured Telnet Session),
          Username/Password Authentication (Local/Remote)
          Management
          Switch Management CLI via console port or Telnet,
          WEB management
          Firmware & Configuration Firmware upgrade via TFTP server,
          Supports dual image,
          Supports auto configuration provision,
          Supports auto firmware upgrade,
          Multiple configuration files,
          Configuration file upload/download via TFTP server
          Remote Monitoring (RMON) 1,2,3 & 9 groups
          SNMP v1,
          v2c,
          v3
          Others BOOTP,
          DHCP client for IP address assignment,
          SNTP,
          NTP,
          IP clustering,
          Port mirroring,
          VLAN mirror,
          sFlow,
          Event/Error Log/Syslog,
          Remote log(RFC3164),
          SMTP,
          MIB I/II,
          LLDP (802.1ab),
          Auto traffic control
          IPv6 Features ICMPv6,
          ICMPv6 Redirect,
          IPv4/IPv6 Dual Protocol Stack,
          IPv6 ACL L2/L3/L4,
          IPv6 Address Types (Unicast),
          Manual Configuration,
          Stateless Auto-configuration
          IPv6 Management Support - IPv6 SNTP,
          SNMP over IPv6,
          IPv6 Telnet,
          Remote IPv6 Ping,
          IPv6 Syslog,
          IPv6 DNS Resolver,
          IPv6 TFTP,
          HTTP over IPv6,
          SSH over IPv6
          IPv6 Neighbor Discovery Router Discovery,
          Duplicate Address Detection,
          Parameter Discovery,
          Prefix Discovery,
          Address Resolution,
          Unreachable Neighbor Detection
          General
          Packet Buffer 1.5MB
          Flash Memory 256MB
          MAC Address Table 16K
          LED Indicators Port,
          Uplink,
          System,
          Diagnostic
          Dimensions 440 x 220 x 44 mm
          Weight 2.35kg
          Operating temperature 0 ÷ 50°C
          Operating humidity 10% ÷ 90%,
          noncondensing
          Power Supply 100 to 240 V,
          50-60 Hz
          Power Consumption 21.48
          Regulatory approvals
          Vibration IEC 68-2-36,
          IEC 68-2-6
          Shock IEC 68-2-29
          Drop IEC 68-2-32
          Certification CE Mark,
          FCC Class A,
          CISPR Class A,
          BSMI
          Manufacturer Edge-corE
          EDGE-CORE
          Managed switch L2, 24x 10/100/1000 RJ-45, 4x 10G SFP+, 19" (Edge-corE ECS4120-28T)
          for special orders only
          Net Price: 711.00 USD
          product card»
          #09352

          Managed switch, 16x 10G Ports, 2x 40G QSFP+ Ports, 19" (Edge-corE ECS5520-18T)

          • 16x 10 10GBASE-T and 2x 40 gigabit QSFP+ ports
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          Standards IEEE 802.3ae (10GBASE-SR/LR/ZR/ER),
          10G DAC/AOC,
          IEEE 802.3z (1000BASE-SX/LX/LHX/ZX)
          Copper Ports 16x 10GBASE-T
          SFP ports 2x 40G QSFP+
          Additional ports 1× RJ45 Console Port,
          1x GE out-of-band Management Port,
          Port USB
          Software features
          Quality of Service 8 hardware queues per port,
          Traffic classification,
          IEEE 802.1p CoS,
          IP Precedence,
          DSCP,
          MAC Access control list (source/destination MAC Ether type priority ID/ VLAN ID ),
          IP Standard access control list (source IP),
          IP extended access control list (source/destination IP protocol TCP/UDP port number),
          Traffic scheduling,
          Strict priority,
          Weighted Round Robin,
          Strict + WRR,
          Single/ Two rate Three color marker,
          Ingress policy map,
          Egress policy map,
          Rate Limiting (Ingress and Egress,
          per port base),
          10G Resolution 64Kbps ~ 10,000Mbps,
          Auto Traffic Control
          L2 and L2+ Features Flow Control IEEE 802.3x for full duplex mode,
          Back-Pressure for half duplex mode,
          Jumbo frames 10KB,
          Broadcast/multicast/ unknown unicast storm control,
          IEEE 802.1D Spanning Tree Protocol (STP),
          IEEE 802.1w Rapid Spanning Tree Protocol (RSTP),
          IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) 64 instances,
          BPDU Guard,
          BPDU filtering,
          Root Guard,
          Loopback detection,
          Non-Spanning Tree loopback detection, ITU-T G.8032 Ethernet Ring Protection,
          Sub 50 msec convergence,
          Revertive operation mode,
          Multiple-ring network,
          Link Aggregation Static trunk,
          IEEE 802.3ad Link Aggregation Control Protocol,
          Trunk Groups 12 up to 8 10G/ 2 40G ports per group,
          Load Balancing SA+DA/SA/DA/SIP+DIP,
          SIP,
          DIP,
          MLAG,
          IGMP v1/v2/v3 snooping,
          IGMP Proxy Reporting,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier,
          MVR (Multicast VLAN Registration),
          Supports 5 multicast VLANs,
          Port mirroring,
          Remote port mirror (RSPAN),
          10GBASE-T copper interfaces,
          Auto-negotiation for port speed and duplex mode,
          Auto MDI/MDI-X
          L3 Routing Static route
          Advanced L3 Routing RIP1/v2,
          RIPng,
          OSPF v2/v3,
          BGP4+,
          VRRP,
          IGMP v1/v2/v3 Proxy,
          PIM-DM/SM,
          PIM-DM6/SM6 - With License (RIP,
          OSPF,
          VRRP,
          BGP,
          PIM,
          IGMP Proxy)
          VLAN Supports 4K VLANs,
          Port-based VLANs,
          IEEE 802.1Q VLANs,
          GVRP,
          VLAN trunking,
          IEEE 802.1v protocol-based VLANs,
          IP subnet-based VLANs,
          MAC-based VLANs,
          Traffic Segmentation,
          L2 Virtual Private VLAN Q-in-Q,
          L2 protocol tunneling (xSTP/CDP/VTP & PVST+),
          CDP/PVST+ filtering
          IPv6 Support IPv4/IPv6 dual protocol stack,
          IPv6 Address Types Stack - Unicast,
          IPv6 Neighbor Discovery,
          Duplicate address,
          Address resolution,
          Unreachable neighbor detection,
          Stateless auto-configuration,
          Manual configuration,
          Remote IPv6 ping,
          IPv6 Telnet suport,
          IPv6 DNS Resolver,
          HTTP over IPv6,
          SNMP over IPv6,
          SSH over IPv6,
          IPv6 Syslog suport,
          IPv6 SNTP support,
          IPv6 TFTP suport,
          RA Guard,
          IPv6 ND Snooping,
          MLD Snooping v1/v2,
          IPv6 source guard,
          DHCPv6 snooping
          Security IEEE 802.1X port based and MAC based authentication,
          Dynamic VLAN assignment,
          auto QoS,
          MAC authentication,
          Web authentication,
          Voice VLAN,
          Guest VLAN,
          User Security for ISP/MSO,
          DHCP Snooping,
          DHCP Option 82,
          IP Source Guard,
          PPPoE IA,
          L2/L3/L4 access control list,
          MAC access control list (source/destination MAC/ Ether type/ priority ID/ VLAN ID ),
          IP standard access control list (source IP),
          IP extended access control list (source/destination IP/ protocol/ TCP/UDP port number),
          IPv6 ACL,
          Network Security,
          Port security,
          Dynamic ARP Inspection,
          Denial of Service protection,
          CPU Guard,
          CPU/Memory threshold and alarm,
          Management Security,
          Login security,
          RADIUS authentication,
          RADIUS accounting,
          RADIUS authorization,
          TACACS + authentication,
          TACACS + accounting,
          TACACS + authorization,
          Management interface access filtering (SNMP/ Web/ Telnet),
          SSH (v2.0) for secure Telnet,
          SSL for HTTPS,
          SNMPv3
          Management
          Management Features CLI via console port or Telnet/SSH,
          Web management,
          SNMP v1/ v2c/ v3,
          Firmware upgrade via TFTP/HTTP/FTP server,
          Multiple configuration files,
          Configuration file upload/download via TFTP/HTTP/FTP server,
          RMON (groups 1/ 2/ 3/ 9),
          DHCP client for IP address assignment,
          DHCP dynamic provision Option 66/67,
          SNTP,
          Event/error log,
          Syslog,
          SMTP,
          Supports LLDP (802.1ab),
          sFlow v4/ v5,
          IP Clustering (with licence),
          Cable diagnostic
          Switching capacity [Gbps] 480
          Packet Forwarding Rate 357.12 Mpps
          MAC Address Table 64K
          Jumbo Frame 10 KB
          Housing / case type Rack Mountable
          Dimensions 43.84 x 28 x 4.34 cm
          Operating temperature 0°C ÷ 50°C
          Operating humidity 5% ÷ 95%,
          non-condensing
          Power internal,
          100~240VAC 50/60Hz,
          Optional 2nd Power module for
          redundancy
          Max Power Consumption 132W
          Certificates CE,
          FCC
          Warranty period 3 years
          Manufacturer Edge-core
          EDGE-CORE
          Managed switch, 16x 10G Ports, 2x 40G QSFP+ Ports, 19" (Edge-corE ECS5520-18T)
          for special orders only
          Net Price: 2 670.00 USD
          product card»
          #09351

          Managed switch, 16x 10G SFP+ Ports, 2x 40G QSFP+ Ports, 19" (Edge-corE ECS5520-18X)

          • 16x 10 gigabit SFP+ and 2x 40 gigabit QSFP+ ports
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          Standards IEEE 802.3ae (10GBASE-SR/LR/ZR/ER),
          10G DAC/AOC,
          IEEE 802.3z (1000BASE-SX/LX/LHX/ZX)
          SFP ports 16x 10G SFP+,
          2x 40G QSFP+
          Additional ports 1× RJ45 Console Port,
          1x GE out-of-band Management Port,
          USB port
          Software features
          Quality of Service 8 hardware queues per port,
          Traffic classification,
          IEEE 802.1p CoS,
          IP Precedence,
          DSCP,
          MAC Access control list (source/destination MAC Ether type priority ID/ VLAN ID ),
          IP Standard access control list (source IP),
          IP extended access control list (source/destination IP protocol TCP/UDP port number),
          Traffic scheduling,
          Strict priority,
          Weighted Round Robin,
          Strict + WRR,
          Single/ Two rate Three color marker,
          Ingress policy map,
          Egress policy map,
          Rate Limiting (Ingress and Egress,
          per port base),
          10G Resolution 64Kbps ~ 10,000Mbps,
          Auto Traffic Control
          L2 and L2+ Features Flow Control IEEE 802.3x for full duplex mode,
          Back-Pressure for half duplex mode,
          Jumbo frames 10KB,
          Broadcast/multicast/ unknown unicast storm control,
          IEEE 802.1D Spanning Tree Protocol (STP),
          IEEE 802.1w Rapid Spanning Tree Protocol (RSTP),
          IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) 64 instances,
          BPDU Guard,
          BPDU filtering,
          Root Guard,
          Loopback detection,
          Non-Spanning Tree loopback detection, ITU-T G.8032 Ethernet Ring Protection,
          Sub 50 msec convergence,
          Revertive operation mode,
          Multiple-ring network,
          Link Aggregation Static trunk,
          IEEE 802.3ad Link Aggregation Control Protocol,
          Trunk Groups 12 up to 8 10G/ 2 40G ports per group,
          Load Balancing SA+DA/SA/DA/SIP+DIP,
          SIP,
          DIP,
          MLAG,
          IGMP v1/v2/v3 snooping,
          IGMP Proxy Reporting,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier,
          MVR (Multicast VLAN Registration),
          Supports 5 multicast VLANs,
          Port mirroring,
          Remote port mirror (RSPAN)
          L3 Routing Static route
          Advanced L3 Routing RIP1/v2,
          RIPng,
          OSPF v2/v3,
          BGP4+,
          VRRP,
          IGMP v1/v2/v3 Proxy,
          PIM-DM/SM,
          PIM-DM6/SM6 - With License (RIP,
          OSPF,
          VRRP,
          BGP,
          PIM,
          IGMP Proxy)
          VLAN Supports 4K VLANs,
          Port-based VLANs,
          IEEE 802.1Q VLANs,
          GVRP,
          VLAN trunking,
          IEEE 802.1v protocol-based VLANs,
          IP subnet-based VLANs,
          MAC-based VLANs,
          Traffic Segmentation,
          L2 Virtual Private VLAN Q-in-Q,
          L2 protocol tunneling (xSTP/CDP/VTP & PVST+),
          CDP/PVST+ filtering
          IPv6 Support IPv4/IPv6 dual protocol stack,
          IPv6 Address Types Stack - Unicast,
          IPv6 Neighbor Discovery,
          Duplicate address,
          Address resolution,
          Unreachable neighbor detection,
          Stateless auto-configuration,
          Manual configuration,
          Remote IPv6 ping,
          IPv6 Telnet suport,
          IPv6 DNS Resolver,
          HTTP over IPv6,
          SNMP over IPv6,
          SSH over IPv6,
          IPv6 Syslog suport,
          IPv6 SNTP support,
          IPv6 TFTP suport,
          RA Guard,
          IPv6 ND Snooping,
          MLD Snooping v1/v2,
          IPv6 source guard,
          DHCPv6 snooping
          Security IEEE 802.1X port based and MAC based authentication,
          Dynamic VLAN assignment,
          auto QoS,
          MAC authentication,
          Web authentication,
          Voice VLAN,
          Guest VLAN,
          User Security for ISP/MSO,
          DHCP Snooping,
          DHCP Option 82,
          IP Source Guard,
          PPPoE IA,
          L2/L3/L4 access control list,
          MAC access control list (source/destination MAC/ Ether type/ priority ID/ VLAN ID ),
          IP standard access control list (source IP),
          IP extended access control list (source/destination IP/ protocol/ TCP/UDP port number),
          IPv6 ACL,
          Network Security,
          Port security,
          Dynamic ARP Inspection,
          Denial of Service protection,
          CPU Guard,
          CPU/Memory threshold and alarm,
          Management Security,
          Login security,
          RADIUS authentication,
          RADIUS accounting,
          RADIUS authorization,
          TACACS + authentication,
          TACACS + accounting,
          TACACS + authorization,
          Management interface access filtering (SNMP/ Web/ Telnet),
          SSH (v2.0) for secure Telnet,
          SSL for HTTPS,
          SNMPv3
          Management
          Management Features CLI via console port or Telnet/SSH,
          Web management,
          SNMP v1/ v2c/ v3,
          Firmware upgrade via TFTP/HTTP/FTP server,
          Multiple configuration files,
          Configuration file upload/download via TFTP/HTTP/FTP server,
          RMON (groups 1/ 2/ 3/ 9),
          DHCP client for IP address assignment,
          DHCP dynamic provision Option 66/67,
          SNTP,
          Event/error log,
          Syslog,
          SMTP,
          Supports LLDP (802.1ab),
          sFlow v4/ v5,
          IP Clustering (with licence),
          Cable diagnostic
          Switching capacity [Gbps] 480
          Packet Forwarding Rate 357.12 Mpps
          MAC Address Table 64K
          Jumbo Frame 10 KB
          Housing / case type Rack Mountable
          Dimensions 43.84 x 28 x 4.34 cm
          Operating temperature 0°C ÷ 50°C
          Operating humidity 5% ÷ 95%,
          non-condensing
          Power internal,
          100~240VAC 50/60Hz,
          Optional 2nd Power module for
          redundancy
          Max Power Consumption 132W
          Certificates CE,
          FCC
          Warranty period 3 years
          Manufacturer Edge-core
          EDGE-CORE
          Managed switch, 16x 10G SFP+ Ports, 2x 40G QSFP+ Ports, 19" (Edge-corE ECS5520-18X)
          for special orders only
          Net Price: 2 030.00 USD
          product card»
          #07033

          Managed switch, 24x 10/100/1000 RJ-45, 4 integrated 1G SFP ports, PoE, 19" (Edge-corE ECS2100-28PP)

          • Full Gigabit Ports: 24x gigabit RJ45 ports and 4 1gigabit SFP ports provide high-speed connections.
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          • Management: Web, CLI (console port), SNMP
          • 24x 30W PoE
          • ecCloud Management
          Standards IEEE 802.3 10Base-T,
          IEEE802.3ab 100Base-T,
          IEEE802.3u 100Base-TX
          Copper ports 24x 10/100/1000 Mbps RJ-45
          SFP ports 4x 1G SFP
          Additional ports 1× RJ45 Console Port
          PoE Ports Supports IEEE 802.3af (15.4 W)/IEEE802.3at (30 W) on each port,
          Total PoE Power Budget 370W,
          Dynamic Power Allocation,
          Auto disable after exceeding power budget,
          PoE Timer
          Software features
          Quality of Service Rate Limiting (Ingress/Egress Port-Based) 64 Kbps ~ 1000 Mbps Resolution 16 Kbps,
          Priority Queues Schedule (WRR/Strict Priority/Hybrid QoS),
          Port-Based QoS,
          IPv4/IPv6 DSCP,
          DiffServ,
          Auto VoIP,
          8 HW Queues per port,
          Dynamic QoS
          L2 and L2+ Features Digital Diagnostic Monitoring (DDM) on 1G SFP port,
          Flow control IEEE 802.3x for full-duplex mode,
          Back-pressure for half-duplex mode,
          IEEE 802.1D Spanning Tree Protocol (STP),
          IEEE 802.1w Rapid Spanning Tree Protocol (RSTP),
          IEEE 802.1s Multiple Rapid Spanning Tree Protocol (MSTP,
          64 instances),Loopback Detection,
          Bridge Protocol Data Unit (BPDU) Filter/Guard,
          Bridge Protocol Data Unit (BPDU) Forward,
          Root Guard,
          Static Trunk,
          IEEE 802.3ad(802.1ax) Link Aggregation Control Protocol (LACP),
          IGMP v1/v2/v3 snooping,
          IGMP Filtering/Throttling,
          IGMP Queries,
          IGMP Immediate leave,
          MLD Snooping,
          LLDP/LLDP-MED,
          Green-Saving IEEE 802.3az/Cable Length/No Link Power-Saving,
          Jumbo Frame 10 K,
          Cable Diagnostic, Q-in-Q,
          mDNS,
          IP Clustering (Soſtware Stacking)
          L3 Features Static Routing,
          RIP
          VLAN Supports 4K IEEE 802.1Q VLANs,
          Port-Based/MAC-Based/IEEE802.1v (Protocol-Based VLAN),
          Guest VLAN,
          Auto Voice VLAN
          IPv6 Support IPv4/IPv6 Dual Protocol Stack,
          IPv6 Management,
          IPv6 Ping/Trace,
          IPv6 Telnet,
          IPv6 Syslog,
          IPv6 TFTP,
          HTTP over IPv6,
          SNMP over IPv6
          Security DDOS Protection,
          CPU Guard (CPU Protection),
          Port Isolation,
          Port Mirror (One to One,
          One to Many),
          Remote Mirror,
          Storm Control,
          Broadcast/Multicast/Unknown Storm Control,
          IEEE 802.1X,
          ACL Ingress Only L2/L3/L4 ACL entry 512 IPv4/IPv6 TCP/UDP-Based,
          MAC-Based ACL,
          Port Security,
          MAC Filter,
          MAC Authentication,
          Port max count per port,
          Dynamic VLAN Assignment,
          Dynamic ARP Inspection,
          AAA (RADIUS/TACACS+),
          IP Source Guard,
          SSH v1.5/v2.0,
          SSL v1/v2/v3,
          SSL IPv4/IPv6,
          SFlow trace on port ingress only,
          Web Authentication
          Management
          Management Features System password protection,
          NTP/SNTP,
          Dual Image/Configuration,
          Configuration upload/download (HTTP/TFTP/FTP/SFTP),
          Firmware upload/download (HTTP/TFTP/FTP/SFTP),
          Auto Firmware Upgrade,
          RMON (groups 1,2,3 and 9),
          SNMP Trap,
          SNMP v1/v2c/v3,
          SNMP Standard/Private MIB,
          Management Access (Console/SNMP/Web /Telnet ),
          Memory Flash Log,
          Event/Error Log/Syslog,
          DHCP v4/v6 Client//DHCP Snooping,
          DHCP Snooping Option82,
          Dynamic Provision (via Option 66,67),
          DHCP Relay v4 (v6),
          Port Mirroring (One to One) TX/RX (both),
          DNS Client without DNS proxy
          Switching capacity [Gbps] 56
          Packet Forwarding Rate 41.7 Mpps
          MAC Address Table 8K
          Jumbo Frame 10 KB
          Housing / case type Rack Mountable
          Dimensions 17.3 × 8.6 × 1.7 in (440 × 220 × 44 mm)
          Operating temperature 0°C ÷ 45°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power internal,
          100~240VAC 50/60Hz
          Max Power Consumption 490 W
          Certificates CE,
          FCC
          Warranty period 3 years
          Manufacturer Edge-core
          EDGE-CORE
          Managed switch, 24x 10/100/1000 RJ-45, 4 integrated 1G SFP ports, PoE, 19" (Edge-corE ECS2100-28PP)
          for special orders only
          Net Price: 719.00 USD
          product card»
          #09366

          Managed switch, 24x 10/100/1000 RJ-45, 4x 100/1000 SFP ports (Edge-corE ECS4100-28T)

          • Performance and Scalability
          • Continuous Availability
          • Comprehensive QoS
          • Robust Multicast Control
          • IPv6 Support
          • Reliability and Energy Efficiency
          • Enhanced Security
          • Superior Management
          • Virtual Private Networks
          Standards IEEE 802.3 100Base-FX,
          IEEE 802.3z 1000BASE-SX/LX/LHX/ZX
          Copper ports 24x 10/100/1000 Mbps RJ-45
          SFP ports 4x 100/1000 Mbps
          Additional ports 1× RJ45 Console port
          Software features
          Quality of Service 8 hardware queues per port,
          IEEE 802.1p CoS,
          IP Precedence,
          DSCP,
          Strict Priority,
          Weighted Round Robin,
          Strict + WRR,
          Ingress policy map,
          Egress policy map,
          Rate Limiting (GE Resolution 64Kbps ~ 1.000Mbps
          L2 Features Tri-speed (10/100/1000BASE-T) copper interfaces,
          Auto-negotiation for port speed and duplex mode,
          Auto MDI/MDI-X,
          100 M/1 G fiber interfaces,
          IEEE 802.3 100BASE-FX,
          IEEE 802.3z (1000BASE-SX/LX/LHX/ZX) transceivers,
          Transceiver-threshold current/rx-power/temperature/tx-power/voltage/high-low alarm and warning,
          Digital Diagnostic Monitoring on SFP port only,
          IEEE 802.3x for full-duplex mode,
          Back-pressure for half-duplex mode,
          Jumbo frames- 12 KB,
          Broadcast/Multicast/Unknown Unicast Storm Control,
          IEEE 802.1D Spanning Tree Protocol,
          IEEE 802.1w Rapid Spanning Tree Protocol,
          IEEE 802.1s Multiple Spanning Tree Protocol (64 instances),
          Spanning-tree restricted-tcn,
          Spanning-tree tc-prop-stop - Stops propagation of topology change information,
          BPDU Guard,
          BPDU Filtering,
          Root Guard,
          BPDU Transparent,
          Loopback Detection,
          Non-Spanning Tree Loopback detection,
          Sub 50 msec convergence (ECS4100-12PH/28P/52P/28TC only),
          Non-revertive operation mode,
          Multiple-ring network,
          Selective Q-in-Q,
          VLAN Translation,
          L2 Protocol tunneling (xSTP/CDP/VTP & PVST+/LLDP),
          CDP/PVST+ Filtering,
          Static Trunk,
          IEEE 802.3ad (LACP),
          16 trunk groups up to 8 GE ports per group,
          Load Balancing (SA+DA/SA/DA/SIP+DIP/SIP/DIP),
          IGMP v1/v2/v3 Snooping,
          IGMP Proxy Reporting,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier,
          IGMP mrouter-forward mode ,
          IGMP router-alert-option-check ,
          IGMP router-port-expire-time ,
          IGMP tcn-flood,
          IGMP tcn-query-solicit,
          IGMP unregistered-data-flood,
          MVR supports 5 multicast VLANs,
          Port mirroring,
          Remote port mirror (RSPAN)
          VLAN Supports 4K VLAN,
          Port-based VLAN,
          IEEE 802.1Q VLAN,
          GVRP (256 VLAN),
          IEEE 802.1v protocol-based VLAN,
          IP Subnet-based VLAN,
          MAC-based VLAN,
          Traffic Segmentation
          IPv6 Support IPv4/IPv6 Dual Protocol stack,
          IPv6 Address Types Stack (Unicast),
          Duplicate address,
          Address resolution,
          Unreachable neighbor detection,
          Stateless auto-configuration,
          Manual configuration,
          Remote IPv6 ping,
          IPv6 Telnet support,
          HTTP over IPv6,
          SNMP over IPv6,
          IPv6 Syslog support,
          IPv6 TFTP support,
          IPv6 MLD filter and throttling,
          IPv6 ND snooping,
          MLD Snooping v1/v2,
          IPv6 source guard,
          DHCPv6 snooping,
          MVR6
          Security IEEE 802.1X port based and MAC based authentication,
          Dynamic VLAN Assignment,
          Dynamic QoS assignment,
          MAC authentication,
          Web authentication,
          Voice VLAN,
          Guest VLAN,
          L2/L3/L4 Access Control List,
          MAC Access control list,
          IP standard access control list,
          IP extended access control list,
          DHCP Snooping,
          DHCP Option 82,
          DHCP Option 82 Relay,
          IP Source Guard,
          IPv6 ACL,
          Port security,
          PPPoE IA,
          Dynamic ARP Inspection,
          CPU guard,
          CPU/Memory threshold and alarm,
          echo-chargen,
          smurf,
          tcp-flooding,
          tcp-null-scan,
          tcp-syn-fin-scan,
          tcp-xmas-scan,
          udp-flooding,
          win-nuke,
          Login Security,
          RADIUS authentication,
          RADIUS accounting,
          TACACS + authentication,
          TACACS + accounting,
          TACACS + authorization,
          Management Interface Access Filtering (SNMP/Web/Telnet),
          SSH (v1.5/v2.0) for security Telnet,
          SSL for HTTPS,
          SNMPv3
          Management
          Management Features CLI via console port or Telnet,
          Web management,
          SNMP (v1/v2c/v3),
          IP clustering (32 members),
          Firmware upgrade via TFTP/HTTP/FTP/SFTP server,
          Dual images,
          Multiple configuration files,
          Configuration file upload/download via TFTP/HTTP/FTP/SFTP server,
          Firmware auto upgrade,
          RMON (groups 1/2/3 and 9),
          BOOTP (DHCP client for IP address assignment),
          DHCP dynamic provision option (66/67),
          SNTP/NTP,
          DNS client,
          Event/Error Log,
          Syslog,
          SMTP,
          Supports LLDP (802.1ab),
          sFlow (v4/v5),
          Cable diagnostics,
          Topology management,
          Performance management,
          Configuration management,
          Event management,
          SNMP management
          Switching capacity [Gbps] 56
          Packet Forwarding Rate 41.6 Mpps
          MAC Address Table 16K
          Jumbo Frame 12 KB
          Housing / case type Rack Mountable
          Dimensions 44 × 22 × 4.4 cm
          Weight 2.2 kg
          Operating temperature 0°C ÷ 50°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100~240VAC 50/60Hz (Front panel)
          Max Power Consumption 20 W
          Certificates FCC Class A,
          CE,
          BSMI,
          Safety Compliance (CB/UL)
          Warranty period 3 years
          Manufacturer Edge-core
          EDGE-CORE
          Managed switch, 24x 10/100/1000 RJ-45, 4x 100/1000 SFP ports (Edge-corE ECS4100-28T)
          for special orders only
          Net Price: 334.00 USD
          product card»
          #09364

          Managed switch, 24x 10/100/1000 RJ-45, 4x 100/1000 SFP, PoE (Edge-corE ECS4100-28P)

          • Performance and Scalability
          • Continuous Availability
          • Comprehensive QoS
          • Robust Multicast Control
          • IPv6 Support
          • Reliability and Energy Efficiency
          • Enhanced Security
          • Superior Management
          • Virtual Private Networks
          • PoE Features
          Standards IEEE 802.3 100Base-FX,
          IEEE 802.3z 1000BASE-SX/LX/LHX/ZX
          Copper ports 24x 10/100/1000 Mbps RJ-45 PoE
          SFP ports 4x 100/1000 SFP
          PoE ports 24x 10/100/1000 Mbps RJ-45,
          PoE+ based on IEEE 802.3bt/802.3af/802.3at,
          Auto disable after exceeding power budget,
          Dynamic Power Allocation,
          PoE Power Budget 190 W
          Additional ports 1× RJ45 Console Port
          Software features
          Quality of Service 8 hardware queues per port,
          IEEE 802.1p CoS,
          IP Precedence,
          DSCP,
          Strict Priority,
          Weighted Round Robin,
          Strict + WRR,
          Ingress policy map,
          Egress policy map,
          Rate Limiting (GE Resolution 64Kbps ~ 1.000Mbps
          L2 Features Tri-speed (10/100/1000BASE-T) copper interfaces,
          Auto-negotiation for port speed and duplex mode,
          Auto MDI/MDI-X,
          100 M/1 G fiber interfaces,
          IEEE 802.3 100BASE-FX,
          IEEE 802.3z (1000BASE-SX/LX/LHX/ZX) transceivers,
          Transceiver-threshold current/rx-power/temperature/tx-power/voltage/high-low alarm and warning,
          Digital Diagnostic Monitoring on SFP port only,
          IEEE 802.3x for full-duplex mode,
          Back-pressure for half-duplex mode,
          Jumbo frames- 12 KB,
          Broadcast/Multicast/Unknown Unicast Storm Control,
          IEEE 802.1D Spanning Tree Protocol,
          IEEE 802.1w Rapid Spanning Tree Protocol,
          IEEE 802.1s Multiple Spanning Tree Protocol (64 instances),
          Spanning-tree restricted-tcn,
          Spanning-tree tc-prop-stop - Stops propagation of topology change information,
          BPDU Guard,
          BPDU Filtering,
          Root Guard,
          BPDU Transparent,
          Loopback Detection,
          Non-Spanning Tree Loopback detection,
          Sub 50 msec convergence (ECS4100-12PH/28P/52P/28TC only),
          Non-revertive operation mode,
          Multiple-ring network,
          Selective Q-in-Q,
          VLAN Translation,
          L2 Protocol tunneling (xSTP/CDP/VTP & PVST+/LLDP),
          CDP/PVST+ Filtering,
          Static Trunk,
          IEEE 802.3ad (LACP),
          16 trunk groups up to 8 GE ports per group,
          Load Balancing (SA+DA/SA/DA/SIP+DIP/SIP/DIP),
          IGMP v1/v2/v3 Snooping,
          IGMP Proxy Reporting,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier,
          IGMP mrouter-forward mode ,
          IGMP router-alert-option-check ,
          IGMP router-port-expire-time ,
          IGMP tcn-flood,
          IGMP tcn-query-solicit,
          IGMP unregistered-data-flood,
          MVR supports 5 multicast VLANs,
          Port mirroring,
          Remote port mirror (RSPAN)
          VLAN Supports 4K VLAN,
          Port-based VLAN,
          IEEE 802.1Q VLAN,
          GVRP (256 VLAN),
          IEEE 802.1v protocol-based VLAN,
          IP Subnet-based VLAN,
          MAC-based VLAN,
          Traffic Segmentation
          IPv6 Support IPv4/IPv6 Dual Protocol stack,
          IPv6 Address Types Stack (Unicast),
          Duplicate address,
          Address resolution,
          Unreachable neighbor detection,
          Stateless auto-configuration,
          Manual configuration,
          Remote IPv6 ping,
          IPv6 Telnet support,
          HTTP over IPv6,
          SNMP over IPv6,
          IPv6 Syslog support,
          IPv6 TFTP support,
          IPv6 MLD filter and throttling,
          IPv6 ND snooping,
          MLD Snooping v1/v2,
          IPv6 source guard,
          DHCPv6 snooping,
          MVR6
          Security IEEE 802.1X port based and MAC based authentication,
          Dynamic VLAN Assignment,
          Dynamic QoS assignment,
          MAC authentication,
          Web authentication,
          Voice VLAN,
          Guest VLAN,
          L2/L3/L4 Access Control List,
          MAC Access control list,
          IP standard access control list,
          IP extended access control list,
          DHCP Snooping,
          DHCP Option 82,
          DHCP Option 82 Relay,
          IP Source Guard,
          IPv6 ACL,
          Port security,
          PPPoE IA,
          Dynamic ARP Inspection,
          CPU guard,
          CPU/Memory threshold and alarm,
          echo-chargen,
          smurf,
          tcp-flooding,
          tcp-null-scan,
          tcp-syn-fin-scan,
          tcp-xmas-scan,
          udp-flooding,
          win-nuke,
          Login Security,
          RADIUS authentication,
          RADIUS accounting,
          TACACS + authentication,
          TACACS + accounting,
          TACACS + authorization,
          Management Interface Access Filtering (SNMP/Web/Telnet),
          SSH (v1.5/v2.0) for security Telnet,
          SSL for HTTPS,
          SNMPv3
          Management
          Management Features CLI via console port or Telnet,
          Web management,
          SNMP (v1/v2c/v3),
          IP clustering (32 members),
          Firmware upgrade via TFTP/HTTP/FTP/SFTP server,
          Dual images,
          Multiple configuration files,
          Configuration file upload/download via TFTP/HTTP/FTP/SFTP server,
          Firmware auto upgrade,
          RMON (groups 1/2/3 and 9),
          BOOTP (DHCP client for IP address assignment),
          DHCP dynamic provision option (66/67),
          SNTP/NTP,
          DNS client,
          Event/Error Log,
          Syslog,
          SMTP,
          Supports LLDP (802.1ab),
          sFlow (v4/v5),
          Cable diagnostics,
          Topology management,
          Performance management,
          Configuration management,
          Event management,
          SNMP management
          Switching capacity [Gbps] 56
          Packet Forwarding Rate 41.7 Mpps
          MAC Address Table 16K
          Jumbo Frame 12 KB
          Dimensions 44 × 33 × 4.4 cm
          Weight 3935 g
          Operating temperature 0°C ÷ 50°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100~240VAC 50/60Hz
          Max Power Consumption 260 W
          Certificates FCC Class A,
          CE,
          Safety Compliance (CB/UL)
          Warranty period 3 years
          Manufacturer Edge-core
          EDGE-CORE
          Managed switch, 24x 10/100/1000 RJ-45, 4x 100/1000 SFP, PoE (Edge-corE ECS4100-28P)
          for special orders only
          Net Price: 697.00 USD
          product card»
          #09353

          Managed switch, 24x GE CSFP Ports, 4x GE Combo Ports (RJ-45/CSFP), 2x 20G QSFP+ Uplink, 19" (Edge-corE ECS4530-54CSFP)

          • 24x GE CSFP Ports, 4x GE Combo Ports (RJ-45/CSFP)
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          Standards IEEE 802.3ae changeable (10GBASE-SR/LR/ZR/ER),
          IEEE 802.3z (1000BASE-SX/LX/LHX/ZX) transceivers
          Ports 24x GE CSFP Ports,
          4x GE Combo Ports (RJ-45/CSFP),
          2x 20G QSFP+ Uplink
          Additional ports 1× RJ45 Console Port,
          1x GE out-of-band Management Port
          Software features
          Quality of Service 8 hardware queues per port,
          Traffic classification,
          IEEE 802.1p CoS,
          IP Precedence,
          DSCP,
          MAC Access control list (source/destination MAC Ether type priority ID/ VLAN ID ),
          IP Standard access control list (source IP),
          IP extended access control list (source/destination IP protocol TCP/UDP port number),
          Traffic scheduling,
          Strict priority,
          Weighted Round Robin,
          Strict + WRR,
          Single/ Two rate Three color marker,
          Ingress policy map,
          Egress policy map,
          Rate Limiting (Ingress and Egress per port base) GE Resolution 64Kbps ~ 1,000Mbps,
          10G Resolution 64Kbps ~ 10,000Mbps,
          20G Resolution 64Kbps ~ 20,000Mbps,
          Auto Traffic Control
          L2 and L2+ Features Flow Control IEEE 802.3x for full duplex mode,
          Back-Pressure for half duplex mode,
          Jumbo frames 10KB,
          Broadcast/multicast/ unknown unicast storm control,
          IEEE 802.1D Spanning Tree Protocol (STP),
          IEEE 802.1w Rapid Spanning Tree Protocol (RSTP),
          IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) 64 instances,
          BPDU Guard,
          BPDU filtering,
          Root Guard,
          Loopback detection,
          Non-Spanning Tree loopback detection,
          ITU-T G.8032 Ethernet Ring Protection,
          Sub 50 msec convergence,
          Revertive operation mode,
          Multiple-ring network,
          Link Aggregation Static trunk,
          IEEE 802.3ad Link Aggregation Control Protocol,
          Trunk Groups 12 up to 8 10G/ 2 40G ports per group,
          Load Balancing SA+DA/SA/DA/SIP+DIP,
          SIP,
          DIP,
          MLAG,
          IGMP v1/v2/v3 snooping,
          IGMP Proxy Reporting,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier,
          MVR (Multicast VLAN Registration),
          Supports 5 multicast VLANs,
          Port mirroring,
          Remote port mirror (RSPAN),
          10GBASE-T copper interfaces,
          Auto-negotiation for port speed and duplex mode,
          Auto MDI/MDI-X
          L3 Routing Static route
          VLAN Supports 4K VLANs,
          Port-based VLANs,
          IEEE 802.1Q VLANs,
          GVRP,
          VLAN trunking,
          IEEE 802.1v protocol-based VLANs,
          IP subnet-based VLANs,
          MAC-based VLANs,
          Traffic Segmentation,
          L2 Virtual Private VLAN Q-in-Q,
          L2 protocol tunneling (xSTP/CDP/VTP & PVST+),
          CDP/PVST+ filtering
          IPv6 Support IPv4/IPv6 dual protocol stack,
          IPv6 Address Types Stack - Unicast,
          IPv6 Neighbor Discovery,
          Duplicate address,
          Address resolution,
          Unreachable neighbor detection,
          Stateless auto-configuration,
          Manual configuration,
          Remote IPv6 ping,
          IPv6 Telnet suport,
          IPv6 DNS Resolver,
          HTTP over IPv6,
          SNMP over IPv6,
          SSH over IPv6,
          IPv6 Syslog suport,
          IPv6 SNTP support,
          IPv6 TFTP suport,
          RA Guard,
          IPv6 ND Snooping,
          MLD Snooping v1/v2,
          IPv6 source guard,
          DHCPv6 snooping
          Security IEEE 802.1X port based and MAC based authentication,
          Dynamic VLAN assignment,
          auto QoS,
          MAC authentication,
          Web authentication,
          Voice VLAN,
          Guest VLAN,
          User Security for ISP/MSO,
          DHCP Snooping,
          DHCP Option 82,
          DHCP Option 80 relay,
          IP Source Guard,
          PPPoE IA,
          L2/L3/L4 access control list,
          MAC access control list (source/destination MAC/ Ether type/ priority ID/ VLAN ID ),
          IP standard access control list (source IP),
          IP extended access control list (source/destination IP/ protocol/ TCP/UDP port number),
          IPv6 ACL,
          Network Security,
          Port security,
          Dynamic ARP Inspection,
          Denial of Service protection,
          CPU Guard,
          CPU/Memory threshold and alarm,
          Management Security,
          Login security,
          RADIUS authentication,
          RADIUS accounting,
          RADIUS authorization,
          TACACS + authentication,
          TACACS + accounting,
          TACACS + authorization,
          Management interface access filtering (SNMP/ Web/ Telnet),
          SSH (v2.0) for secure Telnet,
          SSL for HTTPS,
          SNMPv3
          Management
          Management Features CLI via console port or Telnet/SSH,
          Web management,
          SNMP v1/ v2c/ v3,
          Firmware upgrade via TFTP/HTTP/FTP server,
          Multiple configuration files,
          Configuration file upload/download via TFTP/HTTP/FTP server,
          RMON (groups 1/ 2/ 3/ 9),
          DHCP client for IP address assignment,
          DHCP dynamic provision Option 66/67,
          SNTP,
          Event/error log,
          Syslog,
          SMTP,
          Supports LLDP (802.1ab),
          sFlow v4/ v5,
          IP Clustering,
          Cable diagnostic,
          NTP,
          DNS
          Switching capacity [Gbps] 256
          Packet Forwarding Rate 190.48 Mpps
          MAC Address Table 16K
          Jumbo Frame 10 KB
          Housing / case type Rack Mountable
          Dimensions 44 x 22 x 4.4 cm
          Operating temperature 0°C ÷ 50°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power internal,
          100~240VAC 50/60Hz
          Max Power Consumption 75.4W
          Certificates CE,
          FCC
          Warranty period 3 years
          Manufacturer Edge-core
          EDGE-CORE
          Managed switch, 24x GE CSFP Ports, 4x GE Combo Ports (RJ-45/CSFP), 2x 20G QSFP+ Uplink, 19" (Edge-corE ECS4530-54CSFP)
          for special orders only
          Net Price: 1 460.00 USD
          product card»

top

Page 1 of 8
