MENU#08775
| Channel Number | 1×16 |
|---|---|
| Operation Wavelength | 1260 ~ 1650 nm |
| Insertion Loss | ≤13.6 dB |
| Uniformity | ≤1.2 dB |
| PDL | ≤0.3 dB |
| Return Loss | ≥50 dB |
| Directivity | ≥55 dB |
| Fiber Type | G657A |
| Pigtail Type | 2.0mm loose tube |
| Length | ≥1.2 m |
| Fiber Mark | Input - Yellow, Output - Yellow |
| Operation Temperature | -40 ÷ 85 ℃ |
| Storage Temperature | -40 ÷ 85 ℃ |
Net Price: 8.34 USD Unit: pcs
|
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
