Ports | |
---|---|
RJ-45 (10/100/1000 Mbps) | 48 |
SFP+ 10 Gigabit ports | 4 |
Management Interface | RJ45 Serial Port, Ethernet In/Out Band |
Power over Ethernet (PoE) | |
POE+ IEEE 802.3af/at | Ports 1-40 PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-), Ports 41-48 - 60W PoE++ IEEE 802.3af/at/bt (Pins 1, 2+; 3, 6-) (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-) |
Power dedicated to PoE | 600W |
Voltage Range | 802.3af - 44-57V, 802.3at/bt - 50-57V |
Max. Passive PoE Wattage per Port | 802.3at - 32W, 802.3bt - 64W |
Performance | |
Switching Capacity in Gigabits per Second (Gbps) | 176 |
Forwarding Rate (Mpps) | 130.944 |
Dimensions | 442.4 x 399.6 x 43.7 mm |
Weight | 6.25 kg |
Power | 100-240VAC, 50/60 Hz, 52VDC, 11.54A, 11.5VDC, 5.22A |
Power Supply | AC/DC, Internal, 660W DC |
Operating temperature | -5 ÷ 40°C |
Operating humidity | 5% to 95% , relative, noncondensing |
Certification | CE, FCC, IC |
Shock and Vibration | ETSI300-019-1.4 Standard |
Manufacturer | Ubiquiti |
* For special orders only
Net Price: 1 060.00 USD Unit: pcs
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
