Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.3an, 802.3bz |
---|---|
Copper ports | 24× 100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX), 8× 1/10G SFP+ Slots, 1× RJ45 Console Port, 1× USB Type C Console Port |
Fan Quantity | 2 |
Auto MDI/MDI-X | yes |
Auto-negotiation (Nway) | yes |
Fan Quantity | 1 (Intelligent fan speed adjustment) |
Switching Capacity | 640 Gbps |
Packet Forwarding Rate | 240 Mpps |
MAC Address Table | 32 K |
Packet Buffer Memory | 24 Mb |
Jumbo Frame | 9 KB |
Housing / case type | 19", metal |
Dimensions | 17.3×8.7×1.7 in (440×220×44 mm) |
Operating temperature | -5°C ÷ 50°C |
Operating humidity | 10% ÷ 90%, non-condensing |
Power | 100-240 V AC~50/60 Hz |
Max Power Consumption | 104.9 W (@110V/60Hz), 106.5 W (@220V/50Hz) |
Certificates | CE, FCC ,RoHS |
Warranty period | 5 years |
Manufacturer | TP-Link |
Net Price: 1 250.00 USD Unit: pcs
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
